Tianhui Led Uv Light Water Purification

Rated voltage:

13.7V

Input Voltage:

13.7V

Wavelength:

360~370nm

Input current:

40mA

Shipping:

Express Sea freight · Land freight · Air freight

Inquiry

Product details of the led uv light water purification

Product Overview

led uv light water purification stands out in global market with deft design. Certified to international standards, this product delivers dependable performance. The product has gained a high reputation globally thanks to its huge economic benefits.

Product Information

The details of led uv light water purification are shown for you at below.

Tianhui Led Uv Light Water Purification 4

Description

Tianhui Led Uv Light Water Purification 5

TH-UVC-C01 It is a static UVC LED bacteriostasis module for air and liquid bacteriostasis. It is suitable for closed cavity structure with water tank.

It can be installed at the top, side wall and bottom. The light emitting surface meets the waterproof requirements of IP65. Even if it is installed at the bottom of the water tank, there is no need to worry about water leakage.

The wavelength range of UVC LED used is 260-280nm, which has excellent and efficient sterilization and disinfection effect. The surface is made of UV high permeability quartz glass and UV reflector, which can improve the effective utilization of UVC and significantly improve the sterilization effect.

All materials meet the environmental protection requirements of ROHS and reach, and all water related parts meet the requirements of food safety and water batch.

Application

Tianhui Led Uv Light Water Purification 6

Refrigerator Deodorization

Sterilization for Small Chamber and Area

Parameters

Item	Specifications	Remark
Model	CMF-FSA-TO4A	-
Opening Hole size
Rated voltage	13.7V	-
UVC radiation flux	65mW	-
UVC Wavelength	360~370nm	-
Input current	40mA	-
Input power	0.54W	-
Waterproof grade
Lamp bead life
Dielectric Strength
Size
Net weight
Working temperature	-20℃-60℃	-
Storage temperature	-30℃-70℃	-

Remarks

• Peak wavelength（ λ p) The measurement tolerance is ± 3nm.

• Radiation flux（ Φ e) Measurement tolerance ± 10%.

• The measurement tolerance of forward voltage (VF) is ± 3%.

Tianhui Led Uv Light Water Purification 7

Tianhui Led Uv Light Water Purification 8

Warning Instructions For Use

1. To avoid energy decay, keep the front glass clean.

2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.

3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.

4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not

recommended that the glue of the outlet hole of the module directly contact the drinking water.

5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged

6. Human safety

Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.

If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be

used to protect the body. Attach the following warning labels to products / systems
