TH-UVC-DEM04 275nm UVC Sterilization Module for Drink Machine Ice Machine Air Humidifier Air Cleaner Pet Water Dispenser

    oops...!

    no product data.

    Go to homepage

    TH-UVC-DEM04 is a static UVC LED sterilization module for air and liquid. Applicable to sealed cavity structure with water tank. The UVC light emitting surface shall meet the waterproof requirements of IP67.

    The UVC LED used had a wavelength range of 270- 285nm, It has excellent and efficient sterilization and disinfection effect.

    The surface is a UV high permeable quartzlens, Improving the effective utilization rate of UVC, can significantly improve the sterilization effect.

    All materials meet the environmental protection requirements of RoHS and Reach.

    -1 (6)

    Application

    Drinking machine Ice machine Air humidifier
    Air purifierPet water dispenser Dishwasher

    Parameters

    Item

    Specifications

    Remark

    Model

    TH-UVC-DEM04

    -

    Rated voltage

    DC 12V

    Customizable

    UVC radiation flux

    ≥5mW

    -

    UVC Wavelength

    270-285nm

    -

    Input current

    50±10mA

    According to the lamp bead selection

    Input power

    0.6W

    -

    Waterproof grade

    IP67

    -

    Wire rod

    200±10mm

    Customizable

    Terminals

    XHB2.54,2Pin,yellow

    Customizable

    Lamp bead life

    >10,000 hours

    -

    Dielectric Strength

    DC500 V,1min@10mA, Leakage current

    Working temperature

    -25℃-40℃

    -

    Storage temperature

    -40℃-85℃

    -

    Remarks

    Peak wavelength( λ p) The measurement tolerance is ±3nm.

    Radiant flux( Φ e) Measurement tolerance±10%.

    The measurement tolerance of forward voltage (Vf) is±3%.

    Overall dimension

    Packaging method (reference standard data)

    Warning Instructions For Use

    1. To avoid energy decay, keep the front glass clean.

    2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.

    3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.

    4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not

    recommended that the glue of the outlet hole of the module directly contact the drinking water.

    5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged

    6. Human safety

    Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.

    If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be

    used to protect the body. Attach the following warning labels to products / systems
