Description
Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service for over 22+ years.
Product details of the led uv light water purification
Product Information
When designing Tianhui led uv light water purification, a team of creative designers are employed. It is designed to be ergonomic and user-friendly and thus meets the needs of customers. As any defects are completely eliminated in the inspection process, the product is always in the best quality state. Zhuhai Tianhui Electronic Co., Ltd. thinks long-term development is important, so high quality is necessary.
Description
TH-UVC-T5 is a double-sided light tube, respectively front and back, low-voltage DC drive, constant current chip turn to constant current drive to ensure stable light output and service life of lamp beads long.
The product can be instantly started at nanosecond level without delay. After starting, the stable working state can be achieved.
The lamp body is made of high-purity aluminum it is made by anodizing after construction, with simple and fashionable appearance and no color change. The wavelength range of UVC LED used is 270-280nm, with excellent and efficient sterilization and disinfection. Surface UV high transmittance quartz lens is used to improve the effectiveness of UVC
The use rate can significantly improve the sterilization effect. All materials meet the environmental protection requirements of ROHS and Reach
Application
Sterilization of object surface | Internal sterilization in limited space | Air and water purification |
Parameters
Item |
Specifications |
Remark |
Model |
TH-UVC -T5 Sterilization lamp tube |
- |
Opening Hole size |
- |
- |
Rated voltage |
DC 12V |
- |
UVC radiation flux |
80- 100mW |
- |
UVC Wavelength |
UVC270-280nm / UVA390-400nm |
- |
Input current |
DC400±40mA |
- |
Input power |
1.2W |
- |
Waterproof grade |
|
- |
Lamp bead life |
5,000 Hours |
L50 (DC 12V) |
Dielectric Strength |
DC500 V, 1min@10mA,Leakage current |
|
Size |
Φ15.5 x 147.4mm |
|
Net weight |
30g |
|
Applicable water temperature |
-25℃~40℃ |
- |
Storage temperature |
-40℃~85℃ |
- |
Warning Instructions For Use
1. To avoid energy decay, keep the front glass clean.
2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.
3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.
4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not
recommended that the glue of the outlet hole of the module directly contact the drinking water.
5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged
6. Human safety
Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.
If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be
used to protect the body. Attach the following warning labels to products / systems
Company Advantage
• Our company has established sales outlets in major cities in China. Our products are also exported to Europe, America, Southeast Asia and other regions.
• Since it was established in our company has been focusing on the research and development and production of main products for years. So far, we have accumulated a large amount of professional knowledge and rich production experience.
• Our company is located in a place with convenient transportation. Besides, there are logistics companies leading to domestic and international markets. All these make an advantageous condition for facilitating the distribution and transportation of goods.
Thanks for your interest in Tianhui's UV LED Module, UV LED System, UV LED Diode. If you are interested in our products, please feel free to contact us to place orders. You can enjoy discounts on your first purchase!
