For Medical Vehicle Mounted Uvc Led Air Purifier 80- 100mW by Tianhui

Product details of the vehicle mounted uvc led air purifier

Product Description

Tianhui vehicle mounted uvc led air purifier is built with unique style and compatible structure. The optimum quality and excellent performance makes the product the most sought-after product. Zhuhai Tianhui Electronic Co., Ltd. has extensive design capabilities, rigorous process, a complete quality control system and good after-sales service.

TH-UVC-T5 is a double-sided light tube, respectively front and back, low-voltage DC drive, constant current chip turn to constant current drive to ensure stable light output and service life of lamp beads long.

The product can be instantly started at nanosecond level without delay. After starting, the stable working state can be achieved.

The lamp body is made of high-purity aluminum it is made by anodizing after construction, with simple and fashionable appearance and no color change. The wavelength range of UVC LED used is 270-280nm, with excellent and efficient sterilization and disinfection. Surface UV high transmittance quartz lens is used to improve the effectiveness of UVC

The use rate can significantly improve the sterilization effect. All materials meet the environmental protection requirements of ROHS and Reach

Application

这是一段描述

Sterilization of object surface

Internal sterilization in limited space

Air and water purification

Parameters

这是一段描述

Item	Specifications	Remark
Model	TH-UVC -T5 Sterilization lamp tube	-
Opening Hole size	-	-
Rated voltage	DC 12V	-
UVC radiation flux	80- 100mW	-
UVC Wavelength	UVC270-280nm / UVA390-400nm	-
Input current	DC400±40mA	-
Input power	1.2W	-
Waterproof grade		-
Lamp bead life	5,000 Hours	L50 (DC 12V)
Dielectric Strength	DC500 V, 1min@10mA,Leakage current
Size	Φ15.5 x 147.4mm
Net weight	30g
Applicable water temperature	-25℃~40℃	-
Storage temperature	-40℃~85℃	-

Warning Instructions For Use

这是一段描述

1. To avoid energy decay, keep the front glass clean.

2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.

3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.

4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not

recommended that the glue of the outlet hole of the module directly contact the drinking water.

5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged

6. Human safety

Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.

If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be

used to protect the body. Attach the following warning labels to products / systems

Company Feature

• Good location advantages and developed transportation and infrastructure are conducive to long-term development.
• Tianhui has R&D talents with great technical capabilities and management talents with rich experience. Our company is able to develop sustainably thanks to them.
• Tianhui is praised and favored by customers for high-quality products and professional after-sales services.
• Our company has gradually formed a multi-model, multi-channel, multi-media sales network. And our products are mainly sold to domestic major cities, and exported to North America, Europe, Southeast Asia and other foreign markets.
Tianhui provides discounts for a limit time. Please feel free to contact us for details.
