Description
Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service for over 22+ years.
Tianhui Brand Uv Led Module1 - 10(pieces):15(days) TH-UVC-PA04
Lamp bead life:
>10,000 hours
Input Voltage:
DC 12V
Wavelength:
270-285nm
Product name:
TH-UVC-PA04
Lead_Time:
1 - 10(pieces):15(days),>10(pieces):Negotiable(days)
Product details of the uv led module
Quick Detail
Zhuhai Tianhui Electronic Co., Ltd. can provide customization service for uv led module. Its quality meets the design specifications and customer's requirements. Professional customer service has a positive influence on the development of Tianhui.
Product Description
Compared with similar products, Tianhui's uv led module is more advantageous in the following aspects.
TH-UVC-PA04 is a UVC LED overcurrent water sterilization module. The circuit's driver board is built into the module's interior to save space. The module relies on water flow to dissipate heat and comes with a water flow switch to prevent burnout due to water cutoff. The module is suitable for installation in the middle section of the water circuit.
The UVC LEDs used have a wavelength range of 270-280nm and have excellent and efficient sterilization effects. The internal UVC high reflectivity cavity can effectively improve the utilization of UV light, thus significantly enhancing the sterilization effect.
Application
| Drinking machine | Ice machine | Air humidifier |
| Air purifier | Pet water dispenser | Dishwasher |
Parameters
Item | Specifications | Remark |
Model | TH-UVC-DEM04 | - |
Rated voltage | DC 12V | Customizable |
UVC radiation flux | ≥5mW | - |
UVC Wavelength | 270-285nm | - |
Input current | 50±10mA | According to the lamp bead selection |
Input power | 0.6W | - |
Waterproof grade | IP67 | - |
Wire rod | 200±10mm | Customizable |
Terminals | XHB2.54，2Pin，yellow | Customizable |
Lamp bead life | >10,000 hours | - |
Dielectric Strength | DC500 V,1min@10mA, Leakage current | |
Working temperature | -25℃-40℃ | - |
Storage temperature | -40℃-85℃ | - |
Remarks
Peak wavelength（ λ p) The measurement tolerance is ±3nm.
Radiant flux（ Φ e) Measurement tolerance±10%.
The measurement tolerance of forward voltage (Vf) is±3%.
Overall dimension
Packaging method (reference standard data)
Warning Instructions For Use
1. To avoid energy decay, keep the front glass clean.
2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.
3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.
4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not
recommended that the glue of the outlet hole of the module directly contact the drinking water.
5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged
6. Human safety
Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.
If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be
used to protect the body. Attach the following warning labels to products / systems
Company Advantages
Zhuhai Tianhui Electronic Co., Ltd. is a China-based manufacturer of uv led module. We take special pride in gaining recognition for our excellence. The modern production equipment can fully guarantee the quality of uv led module. We put special emphasis on increasing energy efficiency. We want to lead the way for other companies, for example by investing in solar energy.
Welcome to contact us.
