Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service for over 22+ years.
Oem & Odm 311nm Led Supply for Medical
Product details of the 311nm led
Quick Detail
The design of 311nm led's body frame is based on effect improvement and insufficiencies amendment. The product is guaranteed to be always at its best quality by our stringent quality management system. Tianhui's 311nm led can be used in different industries to meet the needs of customers. Zhuhai Tianhui Electronic Co., Ltd. has abundant material resources for 311nm led.
Product Introduction
Compared with similar products, our 311nm led is provided with the following competitive advantages.
feature
1. Tianhui TH-UVC-PA01-B UVC Led module is specially designed for water disinfection and sterilization. The package emits 265nm UV LED, 275nm UV LED, 280nm UV LED, which can penetrate cells and damage nucleic acids, subsequently causing them to lose microbial activity or die.
2. UV-C LED modules emit UV-C radiation designed to reduce 99.9% of microorganisms and prevent their growth in water1). This reduces unpleasant odors caused by bacteria buildup in or on the equipment, resulting in less maintenance.
3.UVC led module features and safety
UVC lamp: high-quality 265nm , 275nm, 280nm uv led
Radiated power: typically 3.5 mW
Installation: Very easy to install using tape
Operation: Can be operated directly via USB power supply
Safety: LED status indicator lights up during operation
Compliance: RoHS compliant
|
Brand |
Tianhui |
|
Module |
TH-UVC-PA01-B |
|
UVC Wavelength |
265nm uv led ~280nm uv led |
|
Input Current |
300mA |
|
Waterproof Grade of Shell |
IP65 |
|
Rated Voltage |
DC24V |
|
UVC Radiation Flux |
50~240mW |
|
Applicable Water Temperature |
0℃~40℃ |
|
Size |
φ49*90mm |
|
Applicable Water Pressure |
0.5~1Mpa |
265nm 275nm 280nm UVC Led Module Application
Drinking machine/lce machine/Kitchen water purifier
Air humidifier/Pet water dispenser/Tea bar machine
Price Description: please consult with our sales staff for specific prices.
Contact us for real-time quotation, better price for large quantities!
| UVC Led water sterilizer Product Information | ||
| Item | Specification | Remark |
| Module | TH-UVC-PA01-B | - |
| Water Pipe interface | 1/4”, quick connector | Customizable |
| Rated Voltage | DC24V | Customizable |
| UVC Radiation Flux | 50~240mW | Matched 1~5LPM |
| Input Current | 300mA | According to LED Selection |
| Input Power | 5~15W | Matched 1~5LPM |
| Waterproof Grade of Shell | IP65 | - |
| Applicable Water Pressure | 0.5~1Mpa | Optional |
| Wire Rod | 200±10mm | Line Length can be Customized |
| Terminals | XH2.54,White | Terminals can be Customized |
| Lamp Bead Life | 10000~25000 Hours | According to LED Selection |
| Dielectric Strength | DC500 V, 1min@10mA, Leakage Current | |
| Size | φ49*90mm | |
| Net weight | 91±5g | |
| Applicable Water Temperature | 0℃~40℃ | - |
| Storage Temperature | -40℃~85℃ | - |
Warning Instructions For Use
1. To avoid energy decay, keep the front glass clean.
2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.
3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.
4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not
recommended that the glue of the outlet hole of the module directly contact the drinking water.
5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged
6. Human safety
Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.
If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be
used to protect the body. Attach the following warning labels to products / systems
Company Advantages
Zhuhai Tianhui Electronic Co., Ltd. specializes in the R&D, design, and production of 311nm led. We also provide a wide range of related services and products. We have built up a strong customer base. We have developed many new product models which are specially developed and manufactured for satisfying customers' target markets. Tianhui adheres to the desire of becoming a heavily influential 311nm led provider in the future. Inquiry!
All walks of life are welcomed to visit and negotiate.
