Good Selling Uv Light Module New Arrival for Sterilization

Product details of the uv light module

Product Information

Zhuhai Tianhui Electronic Co., Ltd. strictly adopts superior raw material for uv light module. The stability and reliability of this product is largely ensured. After years of development, the product have become the first choice for many customers.

Technical parameters(Preliminary)

1.Rated Voltage：DC24V

2.lnput current：1.2~1.5A

3.Power consumption：28~36W

4.UVC radiant flux：700~1000mW(TBD)

5.UVC peak wavelength：275nm

6. Sterilization rate：>99.9%@25LPM(E.coli)

7.Protective class：P60

8.UVC LED lifespan：L70>2000h(TBD)

9. Applicable flow rate：15~33LPM

   (Sterilization rate declines when flow rate exceeds 25LPM)

10.Applicable water temperature：4~40C

11. Applicable water pressure： <0.4MPa

12. Pressure drop(Pme_-mm)： 25KPa@25LPM，44KPa@33LPM

     (Simulatin result)

13. Wading materials：SUS304， Quartz glass，Food-grade silicone rubber

Company Advantage

• Tianhui, established in has been dedicated to the business of UV LED Module, UV LED System, UV LED Diode for years. Now we become an outstanding enterprise in the industry.
• Nowadays, our company has spread the business range and service network to all parts of the country. We provide timely, total and professional service for the vast number of customers.
• Tianhui pays great attention to talents cultivation which is the reason that we established a professional talents team with rich experience.
Tianhui's UV LED Module, UV LED System, UV LED Diode are safe and practical with high cost performance. If you are interested in the products, you can contact us for consultation or call our hotline directly. We will serve you wholeheartedly.
