Description
Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service for over 22+ years.
Durable270 Nm Led for Curing Printing 1A 3.5~3.7V
UV radiation flux:
1,4~1.7W
Rated voltage:
3.5~3.7V
Consumption Power (W):
3.5~3.7W
Input current:
1A
Input power:
3.5~3.7W
High power UV LED series are designed for high current operation and high power output applications. It incorporates state of the art SMD design and low thermal resistant material. CA3535 is ideal UV light source for curing, printing, and detecting applications.
Application
| Printing | Dental Curing | UV Curing |
| Crime Inspection | Oil Leak Detection | Fluorescence Photography |
Parameters
Item | Specifications |
Model | CUN(x)GF1A Series |
Rated voltage | 3.5~3.7V |
UV radiation flux | 1.4~1.7W |
UV Wavelength | 360~370nm 380~390nm 390~400nm 400~410nm |
Input current | 1A |
Input power | 3.5~3.7W |
Working temperature | -10℃-85℃ |
Storage temperature | -40℃-100℃ |
Remarks
• Peak wavelength（ λ p) The measurement tolerance is ± 3nm.
• Radiation flux（ Φ e) Measurement tolerance ± 10%.
• The measurement tolerance of forward voltage (VF) is ± 3%.
Warning Instructions For Use
1. To avoid energy decay, keep the front glass clean.
2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.
3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.
4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not
recommended that the glue of the outlet hole of the module directly contact the drinking water.
5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged
6. Human safety
Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.
If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be
used to protect the body. Attach the following warning labels to products / systems
Company Advantages
· The production of Tianhui 270 nm led is highly efficient.
· Our dedicated and professional team guarantees the product to be of high quality and stable performance.
· Zhuhai Tianhui Electronic Co., Ltd. has complete quality control system and good after-sales service.
Company Features
· Zhuhai Tianhui Electronic Co., Ltd. is an international company focusing on serving the 270 nm led market.
· Our technology makes 270 nm led be of high quality.
· Innovation is at the heart of everything we believe in and everything we do. We will demonstrate it through our customer-centric and unwavering spirit in how we do business.
Application of the Product
270 nm led developed and produced by our company can be widely used in various industries and professional fields.
Tianhui always provides customers with reasonable and efficient one-stop solutions based on the professional attitude.
