Description
Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service for over 22+ years.
Customized 330 Nm Led Tianhui Manufacture
UV Wavelength:
365-420nm
UV radiation flux:
0.9~1.1W
Input current:
1A
Brand:
Seoul Viosys, SVC
Model:
CUN（X）GF1A
Product details of the 330 nm led
Product Information
Tianhui 330 nm led is manufactured with qualified raw materials that are sourced from reliable suppliers. This product conforms to the international quality standard. Our 330 nm led are popular overseas.
High power UV LED series designed for high current operation, narrow radiation angles and high power output applications.
It combines advanced SMD design and low thermal resistance materials.
The CU3737 is an ideal UV light source for curing, printing and inspection applications.
Application
| Printing | Dental Curing | UV Curing |
| Crime Inspection | Oil Leak Detection | Fluorescence Photography |
Parameters
Item | Specifications |
Model | CUN(x)UB1A series |
Forward Voltage | 360~370nm:3.7V 380~410nm:3.5V 415~425nm:3.6V |
UVA radiation flux | 360~370nm:0.9W 380~410nm:1.1W 415~425nm:1.0W |
UVA Wavelength | 360~370nm 380~410nm 415~425nm |
Input current | 700mA |
Storage temperature | -40℃~100℃ |
Remarks
• Peak wavelength（ λ p) The measurement tolerance is ± 3nm.
• Radiation flux（ Φ e) Measurement tolerance ± 10%.
• The measurement tolerance of forward voltage (VF) is ± 3%.
Warning Instructions For Use
1. To avoid energy decay, keep the front glass clean.
2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.
3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.
4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not
recommended that the glue of the outlet hole of the module directly contact the drinking water.
5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged
6. Human safety
Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.
If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be
used to protect the body. Attach the following warning labels to products / systems
Company Advantage
• Abiding by the service attitude of 'sincere, patient, efficient', our company pays great attention to customers and provides professional and comprehensive services for each consumer.
• Tianhui has vigorously explored the domestic and overseas markets in various ways. UV LED Module, UV LED System, UV LED Diode are currently sold well in some countries and regions in Europe, America, and Australia.
• Our company has a professional team composed of various middle and senior technical talents. The team members are experienced and skilled, so the technical guidance and consultation are guaranteed.
Thanks for visiting. Feel free to consult Tianhui and we will solve your problems wholeheartedly.
