The sterilization characteristics of UVC LED Diode:
In the field of sterilization and disinfection, UVC LED Diode utilizes high-energy ultraviolet radiation to irradiate microorganisms and destroy the nucleic acid structure, thereby achieving the goal of microbial inactivation, and almost all microorganisms including bacteria, viruses, fungi, and algae can be inactivated.UVC LED Diode has the advantages of high sterilization efficiency, long service life, no chemical pollutants, simple operation, etc., and can be widely used in air, water and object surface disinfection and sterilization. With the global spread of novel coronavirus (COVID-19), 270nm UV Led, 280nm UV Led and UVC LED disinfection is considered as an effective method to eliminate novel coronavirus, which has been used in public places, transportation, personal protection and other fields, providing scientific and technological support to curb the spread of COVID-19.
The role of 270nm, 280nm led
The sterilization band is concentrated between 265nm and 280nm, and the lamp bead has high luminous efficiency. It only takes 3 minutes to complete the strong disinfection of items; Due to the environmentally friendly and non-toxic characteristics of UVC LED, this product can disinfect items with high safety requirements such as food, clothing, and baby pacifiers. 270nm UV LED and 280nm UV LED have strong sterilizing power and are suitable for environments requiring high-intensity sterilization such as hospitals and laboratories, as well as daily life and working environments such as homes and offices.
Experience advanced water disinfection with our 270nm led, 280nm led, ledcoupled with VC LED Diode. Our UVC technology ensures effective and reliable water purification, promoting a healthier environment with precision.
Products such as sterilization lamp, disinfection bag, air disinfection and sterilization, water purification and sterilization device equipped with self-developed UVC LED have been launched, which are characterized by high luminous efficiency, low power consumption, high reliability, and a service life of more than 10000 hours. A variety of sterilization methods covering surface sterilization, air sterilization, water sterilization, etc. can be applied in family scenes.
The primary advantage of 270nm UV LED, 280nm UV LED are its germicidal properties. UV LED technology is known for its energy efficiency compared to traditional UV lamps, contributing to lower operational costs. UV LEDs are compact and can be easily integrated into various devices and systems, providing flexibility in design and application.UV LEDs are mercury-free, contributing to a more environmentally friendly option compared to traditional UV lamps that may contain mercury.
When considering the use of UV LED Diode, it's essential to consult with UV LED manufacturers or suppliers to understand specific product specifications and ensure proper integration into intended applications.
PEAKWAVELENGTH | POWER | FORWARDVOLTAGE | FORWARDCURRENT | RADIANTFLUX | RADIATIONANGLE |
270~280nm Led | 16~21W | 11~14V | 1.5A | 600~800mW | 120 |
APPLICATIONS |
UV LED Disinfection,
UV LED Sterilization,
Phototherapy,
Fluorescent Spectroscopy,
Sensor Light,
Bio-Analysis / Detection,
Counterfeit Detectors, etc
|
PEAKWAVELENGTH | POWER | FORWARDVOLTAGE | FORWARDCURRENT | RADIANTFLUX | RADIATIONANGLE |
270~280nm UV LED | 11~16.8W | 11~14V | 1~1.2A | 400~600mW | 120 |
APPLICATIONS |
Disinfection,
Sterilization,
Phototherapy,
Fluorescent Spectroscopy,
Sensor Light,
Bio-Analysis / Detection,
Counterfeit Detectors, etc
|
PEAKWAVELENGTH | POWER | FORWARDVOLTAGE | FORWARDCURRENT | RADIANTFLUX | RADIATIONANGLE |
270~280nm UV LED | 2.5~4.9W | 5~7V | 0.5~0.7A | 80~120mW | 120 |
APPLICATIONS |
Disinfection,
Sterilization,
Phototherapy,
Fluorescent Spectroscopy,
Sensor Light,
Bio-Analysis / Detection,
Counterfeit Detectors, etc
|
Company Advantages
· Tianhui 400nm uv is manufactured using the optimum quality raw material and advanced technology.
· The quality of the product can stand the test of time.
· Zhuhai Tianhui Electronic Co., Ltd. has set up a positive image in 400nm uv industry.
Company Features
· Zhuhai Tianhui Electronic Co., Ltd. supplies high and stable quality of 400nm uv.
· We've developed a sales network abroad in recent years. Over the years of overseas development, we have won the trust and reliability of customers. This gives us great confidence to further expand global 400nm uv markets.
· We aim at the 400nm uv industry, and would like to be number one in this field.
Application of the Product
The 400nm uv produced by Tianhui is widely used in the industry.
Tianhui insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.
