Description
Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service for over 22+ years.
300nm Led CUN(x)GF1A Tianhui
Rated voltage:
3.5~3.7V
Input Voltage:
3.5~3.7V
Wavelength:
360~410nm
Input power:
3.5~3.7W
Model:
CUN(x)GF1A
Product details of the 300nm led
Product Introduction
The whole production of Tianhui 300nm led is under high-efficiency environment. The product is extensively demanded in the market due to its unmatched quality and unsurpassable performance. Warm and meticulous customer service is included in Zhuhai Tianhui Electronic Co., Ltd.'s business philosophy.
High power UV LED series are designed for high current operation and high power output applications. It incorporates state of the art SMD design and low thermal resistant material. CA3535 is ideal UV light source for curing, printing, and detecting applications.
Application
| Printing | Dental Curing | UV Curing |
| Crime Inspection | Oil Leak Detection | Fluorescence Photography |
Parameters
Item | Specifications |
Model | CUN(x)GF1A Series |
Rated voltage | 3.5~3.7V |
UV radiation flux | 1.4~1.7W |
UV Wavelength | 360~370nm 380~390nm 390~400nm 400~410nm |
Input current | 1A |
Input power | 3.5~3.7W |
Working temperature | -10℃-85℃ |
Storage temperature | -40℃-100℃ |
Remarks
• Peak wavelength（ λ p) The measurement tolerance is ± 3nm.
• Radiation flux（ Φ e) Measurement tolerance ± 10%.
• The measurement tolerance of forward voltage (VF) is ± 3%.
Warning Instructions For Use
1. To avoid energy decay, keep the front glass clean.
2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.
3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.
4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not
recommended that the glue of the outlet hole of the module directly contact the drinking water.
5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged
6. Human safety
Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.
If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be
used to protect the body. Attach the following warning labels to products / systems
