Description
Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service for over 22+ years.
255nm Uv Led 15 0.12Wmanufacturing
Rated voltage:
6V
Color:
UVC
Power consumption:
0.12W
Power:
1mW
Lead_Time:
15
Product details of the 255nm uv led
Quick Detail
To manufacture Tianhui 255nm uv led, the quality-approved raw materials is used into the production. The QC team has been always paying close attention to the quality of this product. The 255nm uv led developed and produced by our company is widely applied to many industries and fields, and it can fully meet the diversified needs of customers. Sales and technical support outlets of Zhuhai Tianhui Electronic Co., Ltd. is throughout overseas market.
Product Information
The 255nm uv led of Tianhui is of excellent quality, and it is more remarkable to zoom in on the details.
TH-UV255WP-TO46H
250~260NM uVC LED
Disinfection/Fluorescent Spectroscopy/
Chemical and Biological Analysis
Application
| Disinfection | Fluorescent Spectroscopy | Chemical and Biological Analysis |
Parameters
Item | Specifications |
Model | TH-UV255WP-TO46H |
Rated voltage | 4.8~7V |
UVC radiation flux | 0.5~2.5mW |
UVC Wavelength | 250~260nm |
Input current | 20mA |
Input power | 0.1-0.14W |
Working temperature | -10℃-85℃ |
Storage temperature | -40℃-100℃ |
Remarks
• Peak wavelength（ λ p) The measurement tolerance is ± 3nm.
• Radiation flux（ Φ e) Measurement tolerance ± 10%.
• The measurement tolerance of forward voltage (VF) is ± 3%.
Usage method
Warning Instructions For Use
1. To avoid energy decay, keep the front glass clean.
2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.
3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.
4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not
recommended that the glue of the outlet hole of the module directly contact the drinking water.
5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged
6. Human safety
Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.
If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be
used to protect the body. Attach the following warning labels to products / systems
Company Introduction
Located in zhu hai, Zhuhai Tianhui Electronic Co., Ltd. is a company in the industry. We are professionally engaged in the business of UV LED Module, UV LED System, UV LED Diode. We can meet customer's demand ceaselessly, and continue to provide high quality products and services. We are willing to go hand in hand with you to create a better future.
