Basic Parameter Analysis of 5050LED Lamp Beads

Product specifications: 5050LED lamp bead package product volume: 5050 product wavelength: R: 620-630nm G: 520-530nm B: 465-475nm product brightness: R: 800-900mcd G: 1400-1600mcd B: 300-450mcd welding temperature:: 260 -degree welding time: within 3 seconds of 5050LED lamp bead series display below Tianhui photoelectric high -quality LED lamp bead brand introduction Main features: intelligent anti -connection protection, power supply reverse will not damage IC IC. IC control circuit and LED point light source public power supply. Control circuit and RGB chip integrated in a 5050LED lamp bead packaging component, forming a complete external control pixel. Built -in signal plastic surgery circuit, any pixel point receives the signal and outputs through waveform plastic surgery to ensure that the line waveform distortion of the line will not be accumulated. Built -in power -up reset and power loss reset circuit. Each pixel -point color color color can be displayed at 256 brightness display. Complete a variety of color full -color display, scanning frequency is not less than 400Hz/s. The serial -level interface can complete the data receiving and decoding of the data through a signal line. The transmission distance of any two points does not need to increase any circuit when it does not exceed 5 meters. When the refresh rate is 30 frames/second, the number of couplets is not less than 1024 points. Data delivery speed can reach 800kbps. The color of light is consistent, cost -effective. Later tianhui photocripment mainly application areas: LED full -color light light characters, LED full -color modules, LED full -color soft light strips hard light strips, LED guardrail pipes. LED point light sources, LED pixels, LED alien screens, various electronic products, electrical equipment horses. Tags: & nbsp & nbsp5050LED lamp beads & nbsp5050LED lamp bead basic parameter analysis
